    KS 60

    Single Axis Stages

    KS 60

    Classification: Open type
    Drive type: Ball screw drive
    Sealed type: General environment, semi-sealed
    Repetitive accuracy: ±0.005mm
    Strong carrying capacity
    High-speed transplanting
    Easy assembly and operation

    Quote Now

      [email protected]

      Quick Help: Contact one of our experts and we'll get back to you in 24 hours!

      Download Catalog

        [email protected]

        Quick Help: Contact one of our experts and we'll get back to you in 24 hours!

        Code Ball Screw Linear Guide
        Nominal Outside Diameter (mm) Lead(mm) Basic Dynamic Rated Load (N) Basic Static Rated Load (N) Basic Dynamic Rated Load (N) Basic Static Rated Load (N) Permissible Static Moment
        Pitching Deflection Rolling
        Slide Block A Slide Block S Slide Block A Slide Block S Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2 Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2 Slide Block A1 Slide Block A2 Slide Block S1 Slide Block S2
        KS 6005 P 12 5 3744 6234 13230 7173 21462 11574 152 760 72 367 152 760 72 367 419 838 241 482
        C 3377 5625
        KS 6010 P 12 10 2410 3743 13230 7173 21462 11574 152 760 72 367 152 760 72 367 419 838
        Code Length of Rail (mm) Repetitive Accuracy (mm) Traveling Parallesiam Max.Driving Torque
        P C P C P C
        KS60 150 ±0.003 ±0.005 0.010 / 15 7
        200
        300
        400
        500 ±0.003 ±0.005 0.015 / 15 7
        600

        A: We pay great attention with the quality of our products and we have many quality certificates: ISO9001, ISO14001, CE European Union certification certificate, ROHS certificate etc.

        A: Yes, sample is available. If you are interested, you can contact us by e-mail ([email protected]) to get more photos and information.

        A: Normal order delivery of linear motion products is generally controlled within 1-2 months.
        Normal order delivery for linear unit and higher precision products is generally controlled within 7-15 working days.

        A: Our cooperating transportation companies include DHL, TNT, UPS, etc. Sea transportation, air transportation and express delivery are all available. If you have a specific carrier, please let us know when you place the order.

        A: You can contact us by e-mail ([email protected] ) and we will recommend the most suitable project according to your requirements.

        A: T/T in advance.

        A: SHAC agent in Asia: Singapore, Japan, India
        SHAC agent in Europe: Hungary, Turkey, Israel
        SHAC agent in South America: Brazil

        A: SHAC do quite well in Europe, Asia and South America, also China is a potential market for us. Now SHAC’s distributors have covered more than 32 country and regions.

        A: We are really looking forward to having you as a solid partner of SHAC. Please contact us by e-mail ([email protected] ) , we can start talk and get to know more about each other.
